IRF540NLPBF N-Channel MOSFET, 33 A, 100 V HEXFET, 3-Pin I2PAK Infineon [IRF540NLPBF]; 165-8115
by Infineon
0₫
Mã kho: 1658115
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Channel Type | N |
Maximum Continuous Drain Current | 33 A |
Maximum Drain Source Voltage | 100 V |
Package Type | I2PAK (TO-262) |
Mounting Type | Through Hole |
Pin Count | 3 |
Maximum Drain Source Resistance | 44 mΩ |
Channel Mode | Enhancement |
Maximum Power Dissipation | 130 W |
Transistor Configuration | Single |
Maximum Gate Source Voltage | -20 V, +20 V |
Number of Elements per Chip | 1 |
Width | 4.83mm |
Typical Gate Charge @ Vgs | 71 nC @ 10 V |
Height | 9.65mm |
Series | HEXFET |
Length | 10.67mm |
Transistor Material | Si |
Forward Diode Voltage | 1.2V |
Minimum Operating Temperature | -55 °C |
Maximum Operating Temperature | +175 °C |
