![Infineon IPS65R1K4C6AKMA1 1688116](http://nguyenxuong.com/cdn/shop/products/R8577056-01_444x211.jpg?v=1594097456)
IPS65R1K4C6AKMA1 N-Channel MOSFET, 3.2 A, 700 V CoolMOS C6, 3-Pin IPAK Infineon [IPS65R1K4C6AKMA1]; 168-8116
by Infineon
0₫
Mã kho: 1688116
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Channel Type | N |
Maximum Continuous Drain Current | 3.2 A |
Maximum Drain Source Voltage | 700 V |
Package Type | IPAK (TO-251) |
Mounting Type | Through Hole |
Pin Count | 3 |
Maximum Drain Source Resistance | 1.4 Ω |
Channel Mode | Enhancement |
Maximum Gate Threshold Voltage | 3.5V |
Minimum Gate Threshold Voltage | 2.5V |
Maximum Power Dissipation | 28 W |
Transistor Configuration | Single |
Maximum Gate Source Voltage | -30 V, +30 V |
Number of Elements per Chip | 1 |
Series | CoolMOS C6 |
Minimum Operating Temperature | -55 °C |
Height | 6.22mm |
Width | 2.39mm |
Typical Gate Charge @ Vgs | 10.5 nC @ 10 V |
Transistor Material | Si |
Length | 6.73mm |
Maximum Operating Temperature | +150 °C |
