![DiodesZetex DMN53D0LDW-7 1460595](http://nguyenxuong.com/cdn/shop/products/R9211105-01_444x372.jpg?v=1594275820)
DMN53D0LDW-7 N-Channel MOSFET, 360 mA, 50 V, 6-Pin SOT-363 Diodes Inc [DMN53D0LDW-7]; 146-0595
by DiodesZetex
0₫
Mã kho: 1460595
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Channel Type | N |
Maximum Continuous Drain Current | 360 mA |
Maximum Drain Source Voltage | 50 V |
Package Type | SOT-363 (SC-88) |
Mounting Type | Surface Mount |
Pin Count | 6 |
Maximum Drain Source Resistance | 4.5 Ω |
Channel Mode | Enhancement |
Maximum Gate Threshold Voltage | 1.5V |
Minimum Gate Threshold Voltage | 0.8V |
Maximum Power Dissipation | 310 mW |
Transistor Configuration | Single |
Maximum Gate Source Voltage | -20 V, +20 V |
Number of Elements per Chip | 1 |
Typical Gate Charge @ Vgs | 0.6 nC @ 4.5 V |
Transistor Material | Si |
Maximum Operating Temperature | +150 °C |
Forward Diode Voltage | 1.4V |
Minimum Operating Temperature | -55 °C |
Width | 1.35mm |
Height | 1mm |
Length | 2.2mm |
