RS PRO Voltage Multi timer With SPDT Contacts, 1 Phase, 230 V ac; 102-6131
by RS PRO
0₫
Mã kho: 1026131
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Monitoring Application | Voltage |
| Supply Voltage | 230 V ac |
| Contact Configuration | SPDT |
| Voltage Sensitivity | Overvoltage, Undervoltage |
| Electrical Phase | 1 |
| Voltage Sensing Range | 173 → 218 (Undervoltage) V, 242 → 288 (Overvoltage) V |
| Time Delay | 0.2 → 10 s |
| Frequency Sensing Range | 48 → 63 Hz |
| Minimum Voltage Sensed | 173 (Under Voltage) V, 242 (Over Voltage) V |
| Number of Poles | 1 |
| Dimensions | 17.5 x 66.5 x 89 mm |
| Standards Met | CE, EMC EN 61000-6, IEC |
| Series | L-Series |
| Length | 66.5mm |
| Width | 17.5mm |
| Operating Temperature Range | -20 → +60 °C |
| Terminal Type | Screw |
| Mounting Type | DIN Rail |
| Maximum Voltage Sensed | 218 (Undervoltage) V, 288 (Overvoltage) V |
| Height | 89mm |
| Special Features | Adjustment for Time Delay, Adjustment for Undervoltage Trip Level, Microprocessor Based Relay, Monitors Own Supply & Detects if The Supply Exceeds The Set Under or Over Voltage Trip Levels, True RMS Monitoring, 2 LEDs for the Indication of Operational States |
| Maximum Operating Temperature | +60°C |
| Minimum Operating Temperature | -20°C |
