SPDT-NO/NC Short Roller Lever Microswitc [SW2-06S1-05L0-EA001-Z]; 185-4030
by Zippy
0₫
Mã kho: 1854030
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Actuator Type | Snap |
| Terminal Type | Pre-wired |
| Contact Current Rating | 0.25 |
| Contact Configuration | Single Pole Double Throw (SPDT) |
| IP Rating | IP67 |
| Operating Force | 72 gf |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +85°C |
| Contact Material | Ag Alloy, Brass |
| Case Material | Polyamide |
| Release Force | 15gf |
| Operating Temperature Range | -40 → +85°C |
| Voltage Rating | 125 V ac, 250 V ac |
