| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Actuator Type | Button |
| Terminal Type | Blade |
| Contact Current Rating | 15 A |
| Contact Configuration | DPDT |
| Operating Force | 850 g |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +150°C |
| Contact Material | Silver Cadmium Oxide |
| Case Material | General Purpose Phenolic |
| Operating Temperature Range | -40 → +105°C |
| Standards Met | CSA 16503, CSA Certified, CULus Recognized, UL E23301, UL Recognized |
| Voltage Rating | 125/250V ac |
