SPDT Long Hinge Lever Microswitch, 2 A @ 30 V dc [ABS161350]; 698-9861
by Panasonic
0₫
Mã kho: 6989861
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Actuator Type | Long Hinge Lever |
| Terminal Type | Pre-wired |
| Contact Current Rating | 2 A @ 30 V dc |
| Contact Configuration | SPDT |
| IP Rating | IP67 |
| Operating Force | 0.44 N |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +85°C |
| Contact Material | Silver Nickel Alloy |
| Mechanical Life | 5 x 10^6Operations |
| Release Force | 0.029N |
| Operating Temperature Range | -40 → +85°C |
