SPDT Plunger Microswitch, 3 A [LPHSP]; 883-2063
0₫
Mã kho: 8832063
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Actuator Type | Plunger |
| Terminal Type | Pc Pin |
| Contact Current Rating | 0.125 |
| Contact Configuration | SPDT |
| IP Rating | IP40 |
| Operating Force | 1.8 N |
| Minimum Operating Temperature | -10°C |
| Maximum Operating Temperature | +85°C |
| Contact Material | Silver |
| Case Material | Glass Fibre Reinforced PA |
| Mechanical Life | 10000000Cycles |
| Release Force | 0.28N |
| Voltage Rating | 250V ac |
| Operating Temperature Range | -10 → +85°C |
| Standards Met | CSA, UL |
