EPCOS HighE Series Metal Oxide Varistor 6.6nF 500A, Clamping 710V, Varistor 430V SIOV Case [B72260B0271K001]; 162-0183
by EPCOS
0₫
Mã kho: 1620183
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Varistor Voltage | 430V |
| Maximum AC Voltage Rating | 275V |
| Maximum DC Voltage Rating | 350V |
| Clamping Voltage | 710V |
| Clamping Current | 500A |
| Energy | 860J |
| Series | HighE |
| Maximum Surge Current | 70000A |
| Capacitance | 6.6nF |
| Length | 100mm |
| Depth | 100mm |
| Thickness | 24mm |
| Dimensions | 100 x 100 x 24mm |
| Package/Case | SIOV |
| Lead Pitch | 39mm |
