EPCOS Advanced Series Metal Oxide Varistor 440pF 50A, Clamping 710V, Varistor 430V [B72214S2271K101]; 138-6055
by EPCOS
0₫
Mã kho: 1386055
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Varistor Voltage | 430V |
| Maximum AC Voltage Rating | 275Vrms |
| Maximum DC Voltage Rating | 350V |
| Clamping Voltage | 710V |
| Clamping Current | 50A |
| Energy | 110J |
| Series | Advanced |
| Maximum Surge Current | 6000A |
| Capacitance | 440pF |
| Length | 15.5mm |
| Depth | 18.5mm |
| Thickness | 5.4mm |
| Dimensions | 15.5 x 5.4 x 18.5mm |
| Lead Pitch | 2.2 mm, 7.5 mm |
