GMOV Hybrid Protection Comp 20mm 65Vrms [GMOV-20D650K]; 186-2052
by Bourns
0₫
Mã kho: 1862052
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Varistor Voltage | 65 Vrms, 85 V dc |
| Maximum AC Voltage Rating | 65Vrms |
| Maximum DC Voltage Rating | 85V |
| Clamping Voltage | 185V |
| Clamping Current | 10000A |
| Energy | 70J |
| Series | GMOV |
| Diameter | 23mm |
| Capacitance | 4pF |
| Thickness | 9mm |
| Dimensions | 23 Dia. x 9mm |
| Lead Pitch | 10mm |
