![Panduit lugs [LCAX8-56H-L], PAD408](http://nguyenxuong.com/cdn/shop/products/MFG_LCAX2_0-56-X_a5b9643d-8835-4e19-b750-d4fe0276ea2e_640x640.jpg?v=1597682043)
Wire Termination / Lugs Splices Split Bolts Accessories / Mechanical & Compression Lugs & Splices: Panduit LCAX8-56H-L
One-hole, flex lug, #8 AWG wire, 5/16 stud hole, 45° angle tongue.
| Product Type | Tin-Plated Copper Compression Connectors - Lugs |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 42.491 |
| Stud Hole Size (mm) | 7.9 |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Barrel Length (In.) | 0.42 |
| Barrel Length (mm) | 10.7 |
| Tongue Type | Standard Tongue Width |
| Tongue Width (In.) | 0.56 |
| Tongue Width (mm) | 14.2 |
| Tongue Angle | 45° |
| Tongue Thickness (In.) | 0.05 |
| Tongue Thickness (mm) | 1.3 |
| Overall Length (In.) | 1.2 |
| Overall Length (mm) | 30.5 |
| Color Code | Red |
| Panduit Die Index Number | P21 |
| Burndy Die Index Number | 49 |
| Wire Strip Length (In.) | 42,767 |
| Wire Strip Length (mm) | 12.7 |
| Part Features | Tin plated to inhibit corrosion,color coded barrel,inspection window, beveled wire entry. |
