![Panduit lugs [LCAX1/0-56H-X], PAD269](http://nguyenxuong.com/cdn/shop/products/MFG_LCAX1-14H-X_ee9d0fca-4975-4bf9-a720-7f9e8c4d6f12_640x640.jpg?v=1597682012)
Wire Termination / Lugs Splices Split Bolts Accessories / Mechanical & Compression Lugs & Splices: Panduit LCAX1/0-56H-X
One-hole, flex lug, 1/0 AWG wire, 5/16 stud hole, 45° angle tongue.
| Product Type | Tin-Plated Copper Compression Connectors - Lugs |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 42.491 |
| Stud Hole Size (mm) | 7.9 |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Barrel Length (In.) | 0.72 |
| Barrel Length (mm) | 18.3 |
| Tongue Type | Standard Tongue Width |
| Tongue Width (In.) | 0.85 |
| Tongue Width (mm) | 21.6 |
| Tongue Angle | 45° |
| Tongue Thickness (In.) | 0.13 |
| Tongue Thickness (mm) | 3.3 |
| Overall Length (In.) | 1.58 |
| Overall Length (mm) | 40.1 |
| Color Code | Pink |
| Panduit Die Index Number | P42 |
| Burndy Die Index Number | 12 |
| Wire Strip Length (In.) | 42,828 |
| Wire Strip Length (mm) | 19.1 |
| Part Features | Tin plated to inhibit corrosion,color coded barrel,inspection window, beveled wire entry. |
