Wire Termination / Lugs Splices Split Bolts Accessories / Lug Splice Connector Accessories: Panduit CKSB6-2
Packaged SBC2 and CVRSBC2
| Application | NA |
| Note | Split Bolt Is Nested And Shipped Inside Insulating Cover |
| Product Type | Mechanical Connector |
| Base Material | Flame retardant polypropelene |
| Overall Height (In.) | 1.92 |
| Overall Height (mm) | 48.8 |
| Overall Length (In.) | 2.7 |
| Overall Length (mm) | 67.4 |
| Standards Met | UL94V-0 flame rating for cover, cULus Listed to UL 486A-486B |
| Sub Brand | NA |
| Color | Black |
| Includes | SBC2-C, CVRSBC2 |
| Maximum Operating Temperature (°C) | 90 |
| Maximum Operating Temperature (°F) | 194 |
| Voltage Rating | 600 |
| Width (In.) | 1.32 |
| Width (mm) | 33.5 |
