Panduit Packaged SBC2/0 and CVRSBC2/0 [CKSB1-00]; PAK456

Name: Panduit Packaged SBC2/0 and CVRSBC2/0 [CKSB1-00]; PAK456
Brand: Panduit
SKU: PAK456
Price: 285700.0 VND
Availability: InStock

by Panduit

285.700₫

(Giá chưa VAT).

Mã kho: PAK456

Mã nhà sản xuất: CKSB1-00

Đơn vị tính: RL

Quy cách đóng gói: 1

Quantity

Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)

Wire Termination / Lugs Splices Split Bolts Accessories / Lug Splice Connector Accessories: Panduit CKSB1-00

MÔ TẢ SẢN PHẨM

Packaged SBC2/0 and CVRSBC2/0

_THÔNG SỐ KỸ THUẬT:

Application	NA
Note	Split Bolt Is Nested And Shipped Inside Insulating Cover
Product Type	Mechanical Connector
Base Material	Flame retardant polypropelene
Overall Height (In.)	2.4
Overall Height (mm)	61
Overall Length (In.)	3.1
Overall Length (mm)	78.4
Standards Met	UL94V-0 flame rating for cover, cULus Listed to UL 486A-486B
Sub Brand	NA
Color	Black
Includes	SBC2/0-Q, CVRSBC2/0
Maximum Operating Temperature (°C)	90
Maximum Operating Temperature (°F)	194
Voltage Rating	600
Width (In.)	1.55
Width (mm)	39.3
