Linear Technology LTC1535ISW#PBF, Line Transceiver, RS-422, RS-485, 4.5 → 5.5 V, 28-Pin SOIC [LTC1535ISW#PBF]; 145-6866
0₫
Mã kho: 1456866
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Transmitters | 1 |
| Package Type | SOIC |
| Mounting Type | Surface Mount |
| Pin Count | 28 |
| Number of Receivers | 1 |
| Typical Single Supply Voltage | 4.5 → 5.5 V |
| Data Rate | 250kBd |
| Number of Transceivers | 1 |
| Interface Standards | RS-422, RS-485 |
| Transmitter Signal Type | Differential |
| Receiver Signal Type | Differential |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +85 °C |
| Number of Drivers per Line | 128 |
| Length | 18.08mm |
| Power Supply Type | Single |
| Width | 7.595mm |
| Dimensions | 18.08 x 7.595 x 2.337mm |
| Number of Receivers per Line | 128 |
| Height | 2.337mm |
