![Telemecanique Sensors 9007ML03S0100 1258455](http://nguyenxuong.com/cdn/shop/products/R1258455-01_249x444.jpg?v=1594389409)
IP67 Snap Action Limit Switch Plunger Die Cast Zinc, Metal, NO/NC, 240V [9007ML03S0100]; 125-8455
0₫
Mã kho: 1258455
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Actuator Type | Plunger |
Pole and Throw Configuration | SPDT-DB |
Normal State Configuration | NO/NC |
IP Rating | IP67 |
Maximum Current | 0.416666666666667 |
Housing Material | Die Cast Zinc, Metal |
Maximum AC Voltage | 240V |
Maximum DC Voltage | 28V |
Connection Type | Pre Wired Cable |
Contact Type | Snap Action |
Terminal Type | Pre Wired Cable |
Length | 39.62mm |
Width | 15.75mm |
Standards Met | CE, CSA, E78403, LR 25490 Class 32 11 03, UL |
Maximum Operating Temperature | +104.44°C |
Dimensions | 39.62 x 15.75 x 44.45 mm |
Mechanical Life Minimum | 10000000 Cycles |
Depth | 44.45mm |
Minimum Operating Temperature | -40°C |
