Mean Well ELG-100-36DA, Constant Current / Constant Voltage DALI LED Driver 100W 36V 3A, ELG-100 Series [ELG-100-36DA]; 103-4343
by Mean Well
0₫
Mã kho: 1034343
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Input Voltage | 180 → 305 V ac, 254 → 431 V dc |
| Output Voltage | 36V |
| Operation | Constant Current / Constant Voltage |
| Output Current | 3A |
| Maximum Output Power | 100W |
| Dimming Operation | DALI |
| AC or DC Input Voltage | Ac, Dc |
| IP Rating | IP67 |
| Configuration | Encapsulated |
| Current Rating | 600mA |
| Number of Outputs | 1 |
| Output | 36 V dc @ 2.66 A |
| Standards Met | CB, CE:CCC, CULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, PFC, UL8750 |
| Primary Type | AC-DC, DC-DC |
| Series | ELG-100 |
| Voltage Rating | 180 → 305 V ac, 254 → 431 V dc |
