Vishay 33 μH ±20% Leaded Inductor, Max SRF:6.17MHz, 15.9A Idc, 11.3mΩ Rdc IHTH-1125KZ-5A [IHTH1125KZEB330M5A]; 123-1544
by Vishay
0₫
Mã kho: 1231544
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 33 μH |
| Maximum DC Current | 15.9A |
| Mounting Type | Radial |
| Maximum DC Resistance | 11.3mΩ |
| Tolerance | ±20% |
| Diameter | 28.5mm |
| Height | 10.7mm |
| Dimensions | 28.5 (Dia.) x 10.7mm |
| Maximum Self Resonant Frequency | 6.17MHz |
| Lead Pitch | 17.8mm |
| Series | IHTH-1125KZ-5A |
| Terminal Type | Radial Leaded |
| Lead Diameter | 1.27mm |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +155°C |
