Bourns 100 μH ±10% Ferrite Leaded Inductor, Max SRF:3.7MHz, Q:20, 910mA Idc, 280mΩ Rdc RL622 [RL622-101K-RC]; 172-8502
by Bourns
0₫
Mã kho: 1728502
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 100 μH |
| Maximum DC Current | 910mA |
| Mounting Type | Radial |
| Tolerance | ±10% |
| Diameter | 8.5mm |
| Height | 11mm |
| Dimensions | 8.5 (Dia.) x 11mm |
| Core Material | Ferrite |
| Maximum Self Resonant Frequency | 3.7MHz |
| Lead Pitch | 5mm |
| Series | RL622 |
| Minimum Quality Factor | 20 |
| Lead Diameter | 0.62mm |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +105°C |
