TRACOPOWER THM 6 6W Isolated DC-DC Converter PCB Mount, Voltage in 9 → 18 V dc, Voltage out ±15V dc Medical [THM 6-1223]; 135-0878
by TRACOPOWER
0₫
Mã kho: 1350878
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | ±15V dc |
| Input Voltage Range | 9 → 18 V dc |
| Input Voltage Nominal | 12 V dc |
| Isolation Voltage | 5kV ac |
| Power Rating | 6W |
| Output Current | ±200mA |
| Mounting Type | PCB Mount |
| Number of Outputs | 2 |
| Medical Approved | Yes |
| Package | DIP-24 |
| Load Regulation | 0.01 |
| Minimum Temperature | -40°C |
| Maximum Temperature | +90°C |
| Length | 31.8mm |
| Series | THM 6 |
| Standards Met | ANSI/AAMI ES60601-1:2005/(R)2012, CB Scheme IEC 606010-1, CULus Recognised, ES60601-1, IEC/EN 60601-1 |
| Depth | 10.2mm |
| Width | 20.3mm |
