TRACOPOWER TEN 40WIR 40W Isolated DC-DC Converter Through Hole, Voltage in 18 → 75 V dc, Voltage out 24V dc [TEN 40-4815WIR]; 770-2242
by TRACOPOWER
0₫
Mã kho: 7702242
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 24V dc |
| Input Voltage Range | 18 → 75 V dc |
| Power Rating | 40W |
| Output Current | 1.67A |
| Input Voltage Nominal | 48 V dc |
| Isolation Voltage | 1.6kV dc |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Medical Approved | No |
| Railway Approved | Yes |
| Package | 1 x 2 in |
| Load Regulation | 0.005 |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Series | TEN 40WIR |
| Length | 50.8mm |
| Depth | 10.2mm |
