Murata Power Solutions MTU1 1W Isolated DC-DC Converter Surface Mount, Voltage in 4.5 → 5.5 V dc, Voltage out [MTU1S0512MC]; 167-6205
0₫
Mã kho: 1676205
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 4.5 → 5.5 V dc |
| Input Voltage Nominal | 5 V dc |
| Isolation Voltage | 1kV dc |
| Power Rating | 1W |
| Output Current | 83mA |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Package | SMD |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Depth | 8.4mm |
| Length | 8.2mm |
| Series | MTU1 |
