Cosel SUTW 6W Isolated DC-DC Converter PCB Mount, Voltage in 36 → 76 V dc, Voltage out 30 V dc, ±15 V dc [SUTW64815]; 130-7956
by Cosel
0₫
Mã kho: 1307956
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | ±15 V dc, ±30V dc |
| Output Voltage Adjustment Range | ±14.25 V dc, ±15.75 V dc |
| Input Voltage Range | 36 → 76 V dc |
| Power Rating | 6W |
| Output Current | 200mA |
| Input Voltage Nominal | 48 V dc |
| Isolation Voltage | 500V ac |
| Mounting Type | PCB Mount |
| Number of Outputs | 2 |
| Efficiency | 0.86 |
| Minimum Temperature | -40°C |
| Load Regulation | 750mV |
| Maximum Temperature | +85°C |
| Width | 9.15mm |
| Length | 37.6mm |
| Series | SUTW |
| Standards Met | CE, CUL, CULus Recognised, EN 60950-1, TUV, UL 60950-1 |
| Depth | 26.4mm |
