Cosel STMGFS 24.75W Isolated DC-DC Converter PCB Mount, Voltage in 18 → 76 V dc, Voltage out 3.3V dc [STMGFS30483R3-N1]; 132-7505
by Cosel
0₫
Mã kho: 1327505
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 3.3V dc |
| Output Voltage Adjustment Range | 2.97 → 3.63V |
| Input Voltage Range | 18 → 76 V dc |
| Input Voltage Nominal | 48 V dc |
| Isolation Voltage | 500V dc |
| Power Rating | 24.75W |
| Output Current | 7.5A |
| Mounting Type | PCB Mount |
| Number of Outputs | 1 |
| Efficiency | 0.89 |
| Minimum Temperature | -20°C |
| Load Regulation | 60mV |
| Maximum Temperature | +70°C |
| Standards Met | CE, CUL, EN 60950-1 Complies, UL 60950-1 |
| Depth | 27mm |
| Width | 52mm |
| Series | STMGFS |
| Length | 117mm |
