Cosel MGW 15W Isolated DC-DC Converter PCB Mount, Voltage in 36 → 76 V dc, Voltage out 5V dc [MGW154805-R]; 130-9715
by Cosel
0₫
Mã kho: 1309715
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 5V dc |
| Output Voltage Adjustment Range | 4.935 → 5.240V |
| Input Voltage Range | 36 → 76 V dc |
| Input Voltage Nominal | 48 V dc |
| Isolation Voltage | 500V dc |
| Power Rating | 15W |
| Output Current | 1.5A |
| Mounting Type | PCB Mount |
| Number of Outputs | 2 |
| Efficiency | 0.84 |
| Minimum Temperature | -40°C |
| Load Regulation | 250mV |
| Maximum Temperature | +85°C |
| Width | 25.4mm |
| Depth | 9.9mm |
| Length | 25.4mm |
| Standards Met | CE, CUL, CULus Recognised, EN 60950-1, TUV, UL 60950-1 |
| Series | MGW |
