Cosel CHS 200W Isolated DC-DC Converter PCB Mount, Voltage in 18 → 36 V dc, Voltage out 5V dc [CHS3002405]; 132-5406
by Cosel
0₫
Mã kho: 1325406
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 5V dc |
| Output Voltage Adjustment Range | ±20% |
| Input Voltage Range | 18 → 36 V dc |
| Input Voltage Nominal | 24 V dc |
| Isolation Voltage | 1 kV ac, 500 V dc |
| Power Rating | 200W |
| Output Current | 40A |
| Mounting Type | PCB Mount |
| Number of Outputs | 1 |
| Efficiency | 0.935 |
| Package | DIP |
| Minimum Temperature | -40°C |
| Load Regulation | 10mV |
| Maximum Temperature | +85°C |
| Standards Met | CE, CUL (CSA 60950-1), CULus Recognised, EN 60950-1, UL 60950-1 |
| Width | 22.86mm |
| Series | CHS |
| Depth | 11mm |
| Length | 58.4mm |
