Chinfa DRD30 22.5W Isolated DC-DC Converter DIN Rail Mount, Voltage in 9 → 36 V dc, Voltage out 5V dc [DRD30-05]; 896-2215
by Chinfa
0₫
Mã kho: 8962215
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 5V dc |
| Input Voltage Range | 9 → 36 V dc |
| Input Voltage Nominal | 24 V dc |
| Isolation Voltage | 1.5kV dc |
| Power Rating | 22.5W |
| Output Current | 4.5A |
| Mounting Type | DIN Rail Mount |
| Number of Outputs | 1 |
| Efficiency | 0.81 |
| Load Regulation | ±1V |
| Minimum Temperature | -40°C |
| Maximum Temperature | +71°C |
| Depth | 56.5mm |
| Series | DRD30 |
| Width | 35mm |
| Standards Met | CE EN55022, CE EN55024, CE EN6100-4-2, CE EN6100-4-3, CE EN6100-4-4, CE EN6100-4-5, CE EN6100-4-6, CE EN6100-4-8, CE EN6100-6-2, CE EN6100-6-3, CE EN61204-3, CE ENV50204, CTUVus UL60950-1 Recognized, Shock Resistance IEC 60068-2-27, TUV EN60950-1, UL/cUL |
| Length | 91mm |
