Artesyn Embedded Technologies ERM50 50W Isolated DC-DC Converter Through Hole, Voltage in 66 → 160 V dc, Voltage [ERM03C110]; 172-0178
0₫
Mã kho: 1720178
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 15V dc |
| Input Voltage Range | 66 → 160 V dc |
| Input Voltage Nominal | 110 V dc |
| Isolation Voltage | 1.5kV dc |
| Power Rating | 50W |
| Output Current | 3.33A |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Efficiency | 0.92 |
| Railway Approved | Yes |
| Minimum Temperature | -40°C |
| Load Regulation | ±0.3% |
| Maximum Temperature | +85°C |
| Standards Met | CE, CUL/UL 60950-1, EN 45545-2, EN 50121-3-2, EN 50155, EN 60950-1, EN 61373, IEC 60571, IEC/EN 5055, IEC/EN 60950-1 |
| Series | ERM50 |
| Depth | 12.7mm |
| Length | 57.9mm |
| Width | 36.8mm |
