Wieland Flare Series 110V ac DIN Rail Interface Relay Module, SPDT, Cage Clamp 93.5 → 121V ac/dc [80.010.4131.0]; 341-4828
by Wieland
0₫
Mã kho: 3414828
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 110V ac |
| Minimum Input Voltage | 93.5V ac/dc |
| Maximum Input Voltage | 121V ac/dc |
| Switching Current | 0.25 |
| Contact Configuration | SPDT |
| Mounting Type | DIN Rail |
| Terminal Type | Cage Clamp |
| Length | 70mm |
| Depth | 6.2mm |
| Series | flare |
| Height | 98mm |
| Dimensions | 70 x 6.2 x 98mm |
| Contact Material | Silver Alloy |
| Input Current | 14mA |
| Turn Off Time | 10ms |
| Maximum Operating Temperature | +60°C |
| Minimum Operating Temperature | 0°C |
| Number of Poles | 1 |
| Relay Switching Classification | Interface Relay Module |
| Standards Met | CSA, UL |
| Input Voltage Range | 93.5 → 121V ac/dc |
| Operating Temperature Range | 0 → +60°C |
| Turn On Time | 8ms |
