Hongfa Europe GMBH RMTFL Series 12V dc DIN Rail Interface Relay Module, SPDT, Screw [1RMTFL-12-3]; 137-2115
0₫
Mã kho: 1372115
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Coil Voltage | 12V dc |
Contact Configuration | SPDT |
Switching Current | 16 A |
Mounting Type | DIN Rail |
Terminal Type | Screw |
Length | 76mm |
Depth | 15.8mm |
Series | RMTFL |
Height | 76mm |
Dimensions | 76 x 15.8 x 76mm |
Contact Material | Silver Alloy |
Input Current | 16A |
Maximum Operating Temperature | +70°C |
Turn Off Time | 8ms |
Operating Temperature Range | -40 → +70°C |
Control Resistance | 100mΩ |
Turn On Time | 15ms |
Standards Met | CE, CURus, DVE |
Special Features | AC & DC Coils, Built in Supply Status LED, Built in Test Button & Flag Indicator, Change Over Contacts, Clip and Identification Label, Fjector, Relay, Socket, Supplied Completed, 1 Part Number for Simple Ordering, 35mm DIN Rail Mounting |
Relay Switching Classification | Interface Relay Module |
Number of Poles | 1 |
Minimum Operating Temperature | -40°C |
