Hongfa Europe GMBH 1RM Series 24V dc DIN Rail Interface Relay Module, SPDT, Screw [1RM-24-16A-3]; 137-2106
0₫
Mã kho: 1372106
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 24V dc |
| Switching Current | 16 A |
| Contact Configuration | SPDT |
| Mounting Type | DIN Rail |
| Terminal Type | Screw |
| Length | 76mm |
| Depth | 15.8mm |
| Series | 1RM |
| Height | 65mm |
| Dimensions | 76 x 15.8 x 65mm |
| Contact Material | Silver Alloy |
| Input Current | 16A |
| Relay Switching Classification | Interface Relay Module |
| Special Features | Change Over Contacts, Ejector Clip and Identification Label, LED, Relay, Socket, Supplied Complete, Supply Status LED as Standard 35mm Din Rail Mounting, 1Part Number for Simple Ordering AC & DC Coils, 2 Socket Types For Ease of Installation, 12A and 16A Versions |
| Standards Met | CE, CURus |
| Operating Temperature Range | -40 → +85°C |
| Turn On Time | 15ms |
| Number of Poles | 1 |
| Life | Electrical), Mechanical), 50000 (AC, 100000 (AC, 100000 (DC, 10000000 (DC |
| Control Resistance | 100mΩ |
| Turn Off Time | 8ms |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
