Finder 4C Series 48V dc DIN Rail Interface Relay Module, DPDT, Cage Clamp [4C52 9048 0050]; 613-7259
by Finder
0₫
Mã kho: 6137259
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Coil Voltage | 48V dc |
Contact Configuration | DPDT |
Switching Current | 0.333333333333333 |
Mounting Type | DIN Rail |
Terminal Type | Cage Clamp |
Length | 15.8mm |
Depth | 61.7mm |
Series | 4C Series |
Height | 95.6mm |
Dimensions | 95.6 x 15.8 x 61.7mm |
Contact Material | Silver Alloy |
Operating Temperature Range | -25 → +70°C |
Turn On Time | 10ms |
Turn Off Time | 10ms |
Maximum Operating Temperature | +70°C |
Minimum Operating Temperature | -25°C |
