Finder 39 Series 110V ac/dc DIN Rail Interface Relay Module, SPNO, Screw [39.21.0.125.0060]; 776-1452
by Finder
0₫
Mã kho: 7761452
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 110V ac/dc |
| Switching Current | 0.25 |
| Contact Configuration | SPNO |
| Mounting Type | DIN Rail |
| Terminal Type | Screw |
| Length | 6.2mm |
| Series | 39 Series |
| Depth | 90.7mm |
| Height | 87mm |
| Dimensions | 85 x 6.2 x 87mm |
| Contact Material | Silver Alloy |
| Input Current | 5.6mA |
| Minimum Operating Temperature | -40°C |
| Turn On Time | 5ms |
| Operating Temperature Range | -40 → +70°C |
| Maximum Operating Temperature | +70°C |
| Turn Off Time | 6ms |
