Finder 38 Series 110V ac/dc DIN Rail Interface Relay Module, SPDT, Cage Clamp [38.61.0.125.0060]; 431-7481
by Finder
0₫
Mã kho: 4317481
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 110V ac/dc |
| Switching Current | 0.25 |
| Contact Configuration | SPDT |
| Mounting Type | DIN Rail |
| Terminal Type | Cage Clamp |
| Length | 6.2mm |
| Depth | 76mm |
| Series | 38 Series |
| Height | 93.6mm |
| Dimensions | 6.2 x 75.6 x 93mm |
| Contact Material | Silver Alloy |
| Input Current | 5mA |
| Turn Off Time | 6ms |
| Maximum Operating Temperature | +55°C |
| Number of Poles | 1 |
| Turn On Time | 5ms |
| Operating Temperature Range | -40 → +55°C |
| Minimum Operating Temperature | -40°C |
