Power Integrations LNK613PG Link Switch, CV/CC Switcher, 480mA, 3.3W 7-Pin, DIPC [LNK613PG]; 146-5639
0₫
Mã kho: 1465639
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Power Switch Type | CV/CC Switcher |
| Switch On Resistance | 42Ω |
| Number of Outputs | 1 |
| Current | 480mA |
| Power Rating | 3.3W |
| Mounting Type | Through Hole |
| Package Type | DIPC |
| Pin Count | 7 |
| Dimensions | 9.83 x 6.6 x 3.68mm |
| Power Switch Features | Accurate, Energy Efficient |
| Length | 9.83mm |
| Width | 6.6mm |
| Height | 3.68mm |
| Maximum Operating Temperature | +150 °C |
| Series | LNK613 |
| Minimum Operating Temperature | -40 °C |
