Power Integrations LNK364DN Link Switch, Off Line Switcher, 750mA, 6W 8-Pin, SOC [LNK364DN]; 146-5699
0₫
Mã kho: 1465699
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Power Switch Type | Off Line Switcher |
| Switch On Resistance | 45Ω |
| Number of Outputs | 1 |
| Current | 750mA |
| Power Rating | 6W |
| Mounting Type | Surface Mount |
| Package Type | SOC |
| Pin Count | 8 |
| Power Switch Features | Energy Efficient, Low Power |
| Dimensions | 4.9 x 3.9 x 1.5mm |
| Length | 4.9mm |
| Protection Features | Short Circuit |
| Width | 3.9mm |
| Height | 1.5mm |
| Maximum Operating Temperature | +150 °C |
| Minimum Operating Temperature | -40 °C |
| Series | LNK364 |
