ON Semiconductor NXH80B120H2Q0SG Intelligent Power Switch, Power Module, 40A, 1200V, 103mW 22-Pin, Q0BOOST [NXH80B120H2Q0SG]; 172-3365
0₫
Mã kho: 1723365
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Power Switch Type | Power Module |
| Number of Outputs | 1 |
| Voltage | 1200V |
| Current | 40A |
| Power Rating | 103mW |
| Mounting Type | Screw Mount |
| Package Type | Q0BOOST |
| Pin Count | 22 |
| Dimensions | 66.2 x 32.8 x 16.05mm |
| Power Switch Features | Rectifier Hybrid Module, Solderable Pin, Thermistor |
| Length | 66.2mm |
| Width | 32.8mm |
| Height | 16.05mm |
| Maximum Operating Temperature | +150 °C |
| Minimum Operating Temperature | -40 °C |
