Toshiba GT30J121 IGBT, 30 A 600 V, 3-Pin TO-3P [GT30J121]; 796-5058
by Toshiba
0₫
Mã kho: 7965058
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Maximum Continuous Collector Current | 30 A |
Maximum Collector Emitter Voltage | 600 V |
Maximum Gate Emitter Voltage | ±20V |
Maximum Power Dissipation | 170 W |
Package Type | TO-3P |
Mounting Type | Through Hole |
Channel Type | N |
Pin Count | 3 |
Switching Speed | 1MHz |
Transistor Configuration | Single |
Length | 15.9mm |
Width | 4.8mm |
Height | 20mm |
Dimensions | 15.9 x 4.8 x 20mm |
Maximum Operating Temperature | +150 °C |
