IXYS IXA60IF1200NA IGBT, 88 A 1200 V, 4-Pin SOT-227B [IXA60IF1200NA]; 146-1761
by IXYS
0₫
Mã kho: 1461761
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Continuous Collector Current | 88 A |
| Maximum Collector Emitter Voltage | 1200 V |
| Maximum Gate Emitter Voltage | ±20V |
| Maximum Power Dissipation | 290 W |
| Package Type | SOT-227B |
| Mounting Type | Surface Mount |
| Channel Type | N |
| Pin Count | 4 |
| Transistor Configuration | Single |
| Length | 38.23mm |
| Width | 25.25mm |
| Height | 9.6mm |
| Dimensions | 38.23 x 25.25 x 9.6mm |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +125 °C |
