Fuji Electric 2MBI100VA-060-50, M263 Series IGBT Module, 100 A max, 600 V, Surface Mount [2MBI100VA-060-50]; 110-9124
0₫
Mã kho: 1109124
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Configuration | Series |
| Transistor Configuration | Series |
| Maximum Continuous Collector Current | 100 A |
| Maximum Collector Emitter Voltage | 600 V |
| Maximum Gate Emitter Voltage | ±20V |
| Channel Type | N |
| Mounting Type | Surface Mount |
| Package Type | M263 |
| Pin Count | 7 |
| Maximum Power Dissipation | 650 W |
| Dimensions | 94 x 34 x 30mm |
| Height | 30mm |
| Length | 94mm |
| Maximum Operating Temperature | +150 °C |
| Width | 34mm |
