TE Connectivity 7-Way IDC Connector Socket for Cable Mount, 1-Row [5-103957-6]; 161-4978
0₫
Mã kho: 1614978
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 7 |
| Number of Rows | 1 |
| Gender | Female |
| Pitch | 2.54mm |
| Mounting Type | Cable Mount |
| Body Orientation | Straight |
| Termination Method | IDC |
| Current Rating | 3A |
| Contact Plating | Gold |
| Series | AMPMODU MTE |
| Minimum Operating Temperature | -65°C |
| Maximum Operating Temperature | +105°C |
| Voltage Rating | 600 V ac |
| Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic |
