RS PRO 1 Core 16 mm² Mains Power Cable, Black 100m, 750 V, 6381TQ H07BN4-F; 836-0855
by RS PRO
0₫
Mã kho: 8360855
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Cross Sectional Area | 16 mm² |
| Sheath Colour | Black |
| American Wire Gauge | 5 AWG |
| Core Strands | 151/0.35 mm |
| Insulation Material | PVC |
| Outer Diameter | 10.8 → 13.4mm |
| Length | 100m |
| Voltage Rating | 750 V |
| Conductor Material | Copper |
| Maximum Operating Temperature | +90°C |
| Standards Met | Euroclass Eca |
| Harmonised Code | H07BN4-F |
| Minimum Operating Temperature | -40°C |
