Analog Devices AD7305BRZ, 4-Channel 8 bit Parallel DAC, 1Msps, 20-Pin SOIC W [AD7305BRZ]; 427-212
0₫
Mã kho: 427212
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Resolution | 8 bit |
| Number of DAC Channels | 4 |
| Digital Interface Type | Parallel |
| Mounting Type | Surface Mount |
| Package Type | SOIC W |
| Power Supply Type | Dual, Single |
| Conversion Rate | 1Msps |
| Typical Single Supply Voltage | 3 V, 5 V |
| Voltage Reference | External |
| Architecture | R-2R, Resistor String |
| Pin Count | 20 |
| Maximum Settling Time | 2µs |
| Output Polarity | Bipolar, Unipolar |
| Full Scale Error | ±4LSB |
| Height | 2.35mm |
| Dimensions | 13 x 7.6 x 2.35mm |
| Length | 13mm |
| Width | 7.6mm |
| Maximum Operating Temperature | +85 °C |
| Integral Nonlinearity Error | ±1LSB |
| Minimum Operating Temperature | -40 °C |
| Typical Dual Supply Voltage | ±5V |
