![Analog Devices AD7247JNZ 7094850](http://nguyenxuong.com/cdn/shop/products/R6248034-06_a18c9dd5-bbf5-47c4-bb1a-b9d7536b1cbc_444x336.jpg?v=1594381933)
Analog Devices AD7247JNZ, 2-Channel 12 bit Parallel DAC, 24-Pin PDIP [AD7247JNZ]; 709-4850
0₫
Mã kho: 7094850
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Resolution | 12 bit |
Number of DAC Channels | 2 |
Digital Interface Type | Parallel |
Mounting Type | Through Hole |
Package Type | PDIP |
Power Supply Type | Dual, Single |
Typical Single Supply Voltage | 15 V |
Voltage Reference | External, Internal |
Architecture | R-2R, Resistor String |
Pin Count | 24 |
Maximum Settling Time | 10µs |
Output Polarity | Bipolar, Unipolar |
Full Scale Error | ±5LSB |
Width | 6.35mm |
Minimum Operating Temperature | -40 °C |
Typical Dual Supply Voltage | ±15V |
Integral Nonlinearity Error | ±1LSB |
Length | 31.75mm |
Dimensions | 31.75 x 6.35 x 3.3mm |
Maximum Operating Temperature | +85 °C |
Height | 3.3mm |
