Analog Devices AD7224KRZ-18, 8 bit Serial DAC, 18-Pin SOIC [AD7224KRZ-18]; 145-7671
0₫
Mã kho: 1457671
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Resolution | 8 bit |
| Number of DAC Channels | 1 |
| Digital Interface Type | Serial |
| Mounting Type | Surface Mount |
| Package Type | SOIC |
| Power Supply Type | Dual, Single |
| Typical Single Supply Voltage | 11.4 → 16.5 V |
| Voltage Reference | Internal |
| Architecture | R-2R |
| Pin Count | 18 |
| Maximum Settling Time | 20µs |
| Output Polarity | Bipolar, Unipolar |
| Full Scale Error | ±3/2LSB |
| Length | 11.75mm |
| Maximum Operating Temperature | +85 °C |
| Dimensions | 11.75 x 7.6 x 2.35mm |
| Minimum Operating Temperature | -40 °C |
| Typical Dual Supply Voltage | 14.25 → 15.75V |
| Width | 7.6mm |
| Integral Nonlinearity Error | ±1LSB |
| Height | 2.35mm |
