Analog Devices AD5680BRJZ-2500RL7, 18 bit Serial DAC, 8-Pin SOT-23 [AD5680BRJZ-2500RL7]; 809-9314
0₫
Mã kho: 8099314
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Resolution | 18 bit |
| Number of DAC Channels | 1 |
| Digital Interface Type | Serial (SPI/QSPI/Microwire) |
| Mounting Type | Surface Mount |
| Package Type | SOT-23 |
| Power Supply Type | Single |
| Typical Single Supply Voltage | 4.5 → 5.5 V |
| Voltage Reference | External, Internal |
| Architecture | Resistor String |
| Pin Count | 8 |
| Maximum Settling Time | 85µs |
| Full Scale Error | -1%FSR |
| Maximum Operating Temperature | +105 °C |
| Length | 3mm |
| Height | 1.3mm |
| Width | 1.7mm |
| Dimensions | 3 x 1.7 x 1.3mm |
| Integral Nonlinearity Error | ±2LSB |
| Minimum Operating Temperature | -40 °C |
