Analog Devices AD5544ARSZ, 4-Channel 16 bit Serial DAC, 500ksps, 28-Pin SSOP [AD5544ARSZ]; 912-8778
0₫
Mã kho: 9128778
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Resolution | 16 bit |
| Number of DAC Channels | 4 |
| Digital Interface Type | Serial (SPI) |
| Mounting Type | Surface Mount |
| Package Type | SSOP |
| Power Supply Type | Single |
| Conversion Rate | 500ksps |
| Typical Single Supply Voltage | 5 V |
| Voltage Reference | External |
| Architecture | R-2R, Resistor String |
| Pin Count | 28 |
| Maximum Settling Time | 0.9µs |
| Output Polarity | Unipolar |
| Full Scale Error | ±3mV |
| Width | 5.3mm |
| Integral Nonlinearity Error | ±2LSB |
| Maximum Operating Temperature | +85 °C |
| Height | 1.75mm |
| Length | 10.2mm |
| Dimensions | 10.2 x 5.3 x 1.75mm |
| Minimum Operating Temperature | -40 °C |
