Schurter 20A T Non-Resettable Surface Mount Fuses, 72 V dc, 250 V ac [3403.0287.23]; 144-1833
by Schurter
0₫
Mã kho: 1441833
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Current Rating | 20 A |
| Voltage Rating | 72 V dc, 250 V ac |
| Length | 16.2mm |
| Width | 5.35mm |
| Height | 5.6mm |
| Dimensions | 16.2 x 5.35 x 5.6mm |
| Fuse Speed | T |
| Body Material | Ceramic |
| Breaking Capacity at Maximum Voltage Rating | 100 A @ 250 V ac |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +125°C |
| Terminal Material | Copper Alloy |
| Operating Temperature Range | -55 → +125 °C |
| Series | UMT-H |
