RS PRO 160mA Radial Non-Resettable Wire Ended Fuse, 250V; 767-5086
by RS PRO
0₫
Mã kho: 7675086
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Current Rating | 160 mA |
| Lead Orientation | Radial |
| Voltage Rating | 250 V |
| Body Material | Thermoplastic |
| Body Length | 8.35mm |
| Body Width | 4.3mm |
| Body Height | 7.7mm |
| Wire Length | 4.3 mm, 22 mm |
| Wire Pitch | 5.08mm |
| Breaking Capacity at Maximum Voltage Rating | 35 A @ 250 V ac |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +125°C |
| Wire Diameter | 0.62mm |
